Push-button, 1-gang plus stainless steel, SYS D

توضیحات

For Artec, Trancent, Antique.

With integrated bus coupling unit.
Push-button with two operating buttons,
operating display, two blue status displays
which can be triggered separately, and a
labelling field. The blue operating display
can also be used as an orientation sign. The
lower labelling field can be parameterised as
an additional operating key.
The push-buttons are freely parameterisable
as push-button pairs (dual-surface) or as
single push-buttons.
The device is connected to the bus line with a
bus connecting terminal.
KNX software functions: Switching, toggling,
dimming (single/dual-surface), blind
(single/dual-surface), pulse edges trigger 1-,
۲-, ۴- or 8-bit telegrams (distinction between
short and long operation), pulse edges with 2-
byte telegrams (distinction between short and
long operation), 8-bit linear regulator, scene
retrieval, scene saving, disable functions.
Accessories: Labelling sheets for push-button
plus MTN617819
Contents: With protective hood for plaster.
With bus connecting terminal.
